Overview:

• Advanced IGBT control variant technology for stable and continuous current output.

• Compatible with carbon steel, stainless steel, heat-resistant steel, and composite steel plates.

• Scratch and drawing ARC start mode with high success rate.

• Compact, lightweight design — easy to transport and install.

• Reverse frequency 20 KHz , with 2/4-wheel delivery mechanism.

Performance Features:

• Automatic back-pumping circuit for smooth wire delivery.

• Multiple safety protections including overheat, short-circuit, and arc stability.

• Adaptive current compensation circuit optimizes weld quality.

• Multi-function modes support SAW, MMA, and gouging.

• Pulse output switch with pre-saved welding settings.

• Suitable for industries like shipbuilding, metallurgy, boilers, chemical plants, and bridges.

Standard Accessories:

• 1 pc Welding tractor mounted control box set

• 1 pc Control cable 14*1mm² (10m)

• 1 pc Welding cable 70mm² (10m)

• 1 pc Earthing cable 70mm² (5m)

• 2 pcs Wheel track

Tractor with Trolley Mounted (Included):

• Rated moving voltage: DC 110V

• Moving current: 0.4A

• Welding voltage: DC 110V

• Welding current: 1A

• Speed range: 0.2 – 1.5 m/min

• Wire feed speed: 3 m/min

• Wire diameter: 2.0 – 5.0 mm

Technical Specifications:
