Product Description (Full):

• Technology: Latest inverter with pulse width technology ensuring lightweight and compact build.

• Bridge System: Full wave with full control bridge provides pure DC wave, resulting in excellent welding quality.

• Protection Features:

  • Full protection against overheating, under-voltage, over-voltage, and input surge, ensuring safety during operation.

• Performance Enhancements:

  • Separate current and voltmeter display for precise monitoring.

  • Adjustable ARC force feature for better control.

  • Small welding spatter for a cleaner work environment.

• Remote Control Ready:

  • Standard provision for remote operation with switch (optional: remote with 5m cable).

• Safety:

  • VRD Provision for extra safety during non-welding periods.

• Design:

  • Heavy-duty lug type output terminals.

  • Unique rugged structure providing durability, reliability, and easy maintenance.

• Electrode Compatibility: Acidic and Cellulose electrodes supported.

Technical Specifications:

• Phase: 3PH

• Input Power Voltage: AC 415V * 3PH ±10%

• Frequency: 50/60 Hz

• Rated Input Current: 20.5A

• Rated Output Voltage: 32V

• No-load Voltage: 75V

• Current Adjusting Range: 40-400A

• Duty Cycle: 60%

• Efficiency: 89%

• Welding Electrode Size: 2.5 / 3.2 / 4.0 mm

• Insulation Class: F

• Case Protection Degree: IP21

• Weight: 15 Kg

• Dimensions: 550 × 280 × 545 mm
