Product Description (Full):

• Display: Latest technology LCD display for better visibility and control.

• Technology: Advanced inverter with pulse width technology — lightweight and compact.

• Bridge: Full wave with full control bridge — pure DC output ensuring excellent welding quality.

• Protection:

  • Protection against overheating, under-voltage, over-voltage, and surge in input power for safer operation.

• Performance Features:

  • Adjustable HOT start feature.

  • Adjustable ARC force for stable welding and reduced spatter.

• Safety:

  • VRD provision for operator safety during non-welding time.

• Design:

  • Heavy-duty lug type output terminals.

  • Unique rugged design for reliability, durability, and easy maintenance.

  • Lightweight and portable for ease of handling.

• Electrode Compatibility: Supports Acidic and Cellulose electrodes.

Technical Specifications:

• Phase: 3PH

• Input Power Voltage: AC415V * 3P ±10%

• Frequency: 50/60 Hz

• Rated Input Current: 20.5A

• Rated Output Voltage: 32V

• No-load Voltage: 78V

• Current Adjusting Range: 0-300A

• Duty Cycle: 60%

• Efficiency: 85%

• Welding Electrode Size: 2.5/3.2/4.0 mm

• Insulation Class: F

• Case Protection Degree: IP21

• Weight: 11.5 kg

• Dimensions: 460 × 240 × 393 mm
