• Technology: Latest inverter with pulse width technology, lightweight and compact design.

• Efficiency: High-frequency transformer with soft magnetic ferrite ensures high efficiency.

• Safety Features:

  • VRD low voltage technology for safety during non-welding.

  • Protection against over-voltage, under-voltage, and input surge.

• Energy Saving:

  • Passive power factor correction.

  • Auto main circuit cut-off after 5 seconds of no arc.

• Performance:

  • Adjustable arc starting current for improved starting.

  • Arc force and anti-stick feature for better electrode burning and welding performance.

• Design: Unique rugged design for reliability, durability, and ease of maintenance.

• Electrode Compatibility: Supports Acidic/Cellulose electrodes.

Standard Accessories:

• 1 set electrode holder with 16mm² cable (1.8m) + 35-50 male connector

• 1 set earth clamp with 16mm² cable (1.2m) + 35-50 male connector

Technical Specifications:

• Rated Input Voltage: AC 220V ±10%

• Phase: 1PH

• Frequency: 50/60 Hz

• Rated Input Power: 5 KVA

• Rated Input Current: 37A

• Welding Current Adjustment Range: 20-200A

• No-load Voltage: 72V

• Rated Duty Cycle: 60%

• Machine Efficiency: 85%

• Power Factor: 0.7

• Insulation Grade: F

• Shell Protection Level: IP21S

• Dimensions: 370 × 170 × 320 mm

• Weight: 4.5 Kg
